6.9 Inch 7.0 Inch TFT LCD Module With CTP 280x1424 MIPI RGB Interface

Name: 69 Inch 70 Inch TFT LCD Module With CTP 280x1424 MIPI RGB Interface
Brand: ESEN
Price: 1 USD

Wholesale 6.9 Inch 7.0 Inch TFT LCD Module With CTP 280x1424 MIPI RGB Interface from china suppliers

Brand Name : ESEN

Model Number : TX070-30RB-A1

Certification : ISO9001/ISO14001

Place of Origin : Shenzhen China

MOQ : No MOQ

Price : can be negotiated

Payment Terms : L/C,T/T

Supply Ability : 300K/mth

Delivery Time : 7~14 working days

Packaging Details : Cartons, Capboard, EPE, Blister Tray.

Size : 7.0 inch

Resolution : 280(horizontal)*1424(Vertical)

Interface : MIPI

Connect type : Connector

Color Depth : 16.7M

Technology type : a-Si

Pixel pitch (mm) : 0.12x0.12 0.12x0.12

Pixel Configuration : R.G.B. Vertical Stripe

Display Mode : Normally Black

Viewing Direction : ALL

Gray Scale Inversion Direction : ALL

LCM (W x H x D) (mm) : 38.20*181.47*3.5

Active Area(mm) : 33.6 x 170.88

With /Without TSP : Without TSP

Weight (g) : TBD

LED Numbers : 8 LED

Customization : FPC(Shape,Pin Definition,Connector,EMI Film) Backlight(Dimension,Using Life,LED Color,Luminance) Touch Panel(Shape,Dimension,FPC,Touch Points)

Contact Now

7.0 Inch 6.9 Inch TFT LCD Display with CTP 280x1424 resolution MIPI/RGB interface view angle is all o'clock

Type: TFT

Supplier Type: Manufacture

Place of Origin: GUA

Brand Name: LCD MALL

Resolution: 280x1424

LCD TYPE: WXGA

Driver IC: T-CON

Interface: MIPI(LCM)+IIC(CTP)

Backlight LEDs: 8 chip white LED

Luminance: 400nits

Viewing Angle: ALL/IPS

OD Size (mm): 46.2* 199 * 4.8

AA Size (mm): 33.6 * 170.88

PIN number: 40PIN

Mechanical Drawing

6.9 Inch 7.0 Inch TFT LCD Module With CTP 280x1424 MIPI RGB Interface

Input/Output Terminals
